S-DR-WOB DRY RUNNING SINGLE

SINGLE SEAL WITH BEARING FOR REACTORS WITH LONG SHAFT.

Design Features

• Single Mechanical seal
• Designed for clear fluids.
• Hydraulically-balanced design
• Anti-rotation pin with o-ring protecting seal face

Operating Limits

• Size=20mm~120mm/
• TEMP=up to 80°C without water quench
• Up to 200°C with water quench
• PRESSURE=up to 15kg/cm2.
• SPEED =20m/s/4000fpm
