Carbon physical Property |
||||||||
Category |
Model | Density (g/cm3) | Fractural Strength (MPa) | Compressive Strength (MPa) | Shore Hardness (HSD)+/- (5) | Porosity (%) | Temperature(oC) | |
| Carbongraphite | Hot moulded Carbon | M1 | >1.65 | 65 | 150 | 70 | <0.2 | 180 |
| Sintered Carbon | MJ | >1.75 | 60 | 160 | 85 | <2.5 | 200 | |
| Impregnated Furan Resin(Z) | M106K M120K |
1.75 1.7 |
67 62 |
200 180 |
90 85 |
<1 <1 |
250 250 |
|
| Impregnated Phenol Aldehyde Resin(F) | M106F M120F |
1.75 1.7 |
60 55 |
200 180 |
85 80 |
<1 <1 |
250 250 |
|
| Antimony Carbon(D) | M106D M120D |
2.3 2.3 |
65 60 |
220 220 |
90 90 |
<1.5 <1.5 |
400 400 |
|
